The CAMC H08 6 × 4 left-hand drive diesel tractor is a classic traction equipment designed for the global medium and long-distance heavy-duty transportation market. It was jointly designed by the Italian company Broadcom and integrates the European heavy-duty truck design concept with CAMC's mature manufacturing technology. It is widely suitable for various scenarios such as container trunk transportation, logistics park connection, port transfer, and mineral and building materials transportation. The entire vehicle has undergone rigorous road tests and has been exported in bulk to multiple countries and regions around the world, including Southeast Asia, the Middle East, Africa, and South America. With high reliability, low operating costs, and convenient maintenance, it has gained widespread recognition from overseas customers.
The vehicle is equipped with the Hanma Power CM6D20.450 inline six cylinder high-pressure common rail diesel engine, with a displacement of 10.52L, a rated power of 331kW (450 horsepower), and a maximum torque of 2100N · m. It can output peak torque in the wide speed range of 1000-1500rpm, and has excellent performance in heavy-duty starting, climbing, and overtaking. Matched with the Fasttech 12JSDX240TA-B 12 speed manual transmission, the gears are dense and the transmission is efficient, balancing power and fuel economy; The emission standards cover Euro 3 to Euro 6, and can be flexibly adapted to different national regulatory requirements. The large capacity aluminum alloy fuel tank ensures long-distance transportation.
Adopting a 6 × 4 rear dual drive heavy-duty chassis with a wheelbase of 3400+1350mm, the 7.5T front axle is equipped with an HL458 dual stage deceleration rear axle, which has strong load-bearing capacity and good passability; Standard 12R22.5 vacuum tires (optional 11.00R20), suitable for high-speed and unpaved composite road conditions. The maximum allowable towing weight is 38570kg, equipped with 90 # standard towing saddle, compatible with various types of trailers. The standard left-hand drive layout complies with the traffic regulations of the vast majority of countries around the world, making it convenient to land overseas and having a short license plate operation cycle.
The H08 high top two bedroom cab adopts a four point suspension shock absorption structure, equipped with airbag seats, air conditioning, central locking and electric windows, providing excellent comfort for long-distance driving; Equipped with ABS anti lock braking system as standard, ensuring driving safety. The vehicle parts have strong universality and convenient maintenance, and the global supply of diesel fuel is convenient. Relying on CAMC's global after-sales network and spare parts supply system, we provide efficient, reliable, and economical heavy-duty traction solutions for overseas logistics customers.
1.450 horsepower powerful, low-speed high torque
Hanma 10.52L inline six cylinder high-pressure common rail diesel engine, 331kW/450 horsepower, peak torque 2100N · m, can unleash high torque at 1000rpm, with ease in heavy load climbing and starting, suitable for various complex transportation conditions.
2.Fast 12 speed gearbox, efficient and fuel-efficient transmission
Fast 12JSDX240TA-B 12 speed manual transmission, with dense gears, smooth shifting, high transmission efficiency, balancing power output and fuel economy, and controllable long-term fuel consumption costs.
3.6 × 4 heavy-duty chassis with excellent traction capability
7.5T front axle+HL458 double reduction rear axle, 3400+1350mm wheelbase, maximum towing weight 38570kg, 90 # standard saddle compatible with various trailers, balancing load capacity and passability, suitable for heavy-duty mainline transportation.
4.Italian Broadcom design, high top comfortable cabin
The H08 cab is jointly designed by Broadcom Italy, with a high top two bedroom layout, four point suspension shock absorption, airbag seats, and air conditioning. It has low fatigue during long-distance driving and is comparable to European heavy-duty trucks in terms of driver comfort.
5.Mature and reliable, convenient global maintenance
The H08 platform has been validated at the million kilometer level and has a low failure rate; Strong universality of accessories, convenient global procurement, no pressure on diesel fuel supply, coupled with CAMC global after-sales system, ensuring high attendance rate of the fleet.
Customer Review 1 | Southeast Asian Mainline Logistics Operator
“We have been using the H08 tractor for more than three years, with 450 horsepower to pull containers and run on the main line very steadily. The 12 speed gearbox changes gears smoothly, and the fuel consumption is lower than that of cars in the same class. The driver in the high top cab is comfortable to rest, and the accessories are easy to buy locally. The CAMC after-sales response is timely, making it the main model of our fleet. "
Customer Review 2 | African Mineral Transport Contractor
“The mining area has poor road conditions and high transportation intensity. The H08 chassis is sturdy and has good passability. It can handle heavy loads and climb hills with 450 horsepower without any problem. The left-hand drive version is directly registered with a low failure rate and maintenance costs are much cheaper than European cars. It is very suitable for our operating environment. "
Q1: What engine does the CAMC H08 tractor truck use?
A: It is equipped with a CAMC/Hanma CM6D20.450 inline-6 cylinder high-pressure common rail diesel engine, with 10.52L displacement, 331kW (450HP) rated power and 2100N·m maximum torque.
Q2: What is the gearbox configuration?
A: It is matched with a FAST 12JSDX240TA-B 12-speed manual transmission, providing smooth shifting and efficient power delivery for both highway and heavy-load conditions.
Q3: What is the driving layout and maximum towing capacity?
A: It adopts a 6×4 heavy-duty chassis with left-hand drive (LHD), and the maximum authorized towing mass is 38,570 kg, equipped with a standard 90# fifth wheel.
Q4: What are the key chassis specifications?
A: 7.5T front axle, HL458 double-reduction rear axles, 3400+1350mm wheelbase, 12R22.5 tubeless tires (11.00R20 optional), and aluminum alloy fuel tank.
Q5: What emission standards does it support?
A: It supports Euro III to Euro VI emission standards, flexible to meet different national regulatory requirements.
Q6: What about the cab and comfort features?
A: The H08 high-roof double-berth cab is co-designed by Italy Bertone, with four-point suspension, air-suspension seat, A/C, power windows and central locking, ensuring comfortable long-haul driving.
Q7: What safety features does it have?
A: It is equipped with ABS anti-lock braking system as standard, heavy-duty axles and reliable braking system, ensuring safe operation under various road conditions.
Q8: What after-sales support does CAMC provide overseas?
A: CAMC offers multilingual technical support, global spare parts supply and on-site maintenance service to ensure high fleet uptime for overseas customers.
