54.4*40.9*14.5cm
CAMC
CAMC Type2 wall mounted charging station is a new generation of minimalist intelligent charging device designed for global household and commercial scenarios. It abandons the traditional screen structure and adopts an integrated minimalist body design, which is not easy to accumulate dust, easy to clean, durable and resistant to dirt. Long term use can keep the body clean and beautiful. The whole machine has zero threshold operation, full safety protection, and is suitable for use by various groups of people. It is equipped with a European standard Type2 charging interface and compatible with the vast majority of mainstream new energy vehicle models. It is a cost-effective preferred device for global civilian new energy replenishment.
The device is equipped with a dedicated blue breathing light status indicator system, which provides visual feedback on the entire charging status: constant light indicates normal charging, flashing indicates standby readiness, and the light goes out indicates power-off standby. The status is clear at a glance, and the device's operating status can be quickly identified without complex operations. The screen free minimalist structure reduces the number of openings on the body, lowers the probability of failure, and provides better dust and moisture resistance, making it suitable for various indoor and outdoor installation environments.
Support true one click plug and play, no need for APP binding, no need for card activation, no need for additional settings. Simply plug in the gun and it will automatically start charging, greatly reducing the threshold for use and perfectly adapting to various users such as the elderly and beginners. The home experience will be greatly upgraded. The body comes standard with a Type2 European standard charging gun, which is widely compatible with over 99% of domestic and foreign new energy vehicle models such as Tesla, BYD, NIO, and Xiaopeng, with no blind spots in vehicle adaptation.
Built in high-end A-type residual current device, equipped with 6mA DC leakage detection function, can accurately monitor AC/DC leakage hazards, and prevent electric shock by quickly cutting off power in 0.1 seconds. Integrating multiple protection mechanisms including overvoltage, undervoltage, overcurrent, surge, lightning protection, and high temperature, building a comprehensive safety protection system to eliminate various charging safety risks. The body structure is stable and durable, easy to install, and simple to operate, providing global users with a minimalist, safe, and worry free all-weather charging solution.
| Power rating (Double gun) | 14KW(1 Phase) |
| Charging interface type | IEC 61851 |
| Output current | 32A |
| Frequency | 45-65Hz |
| Overvoltage protection | Yes |
| undervoltage protection | Yes |
| overload protection | Yes |
| short circuit protection | Yes |
| ground protection | Yes |
| over temperature protection | Yes |
| lightning protection | Yes |
| WIFI/4G/OCPP1.6/LAN | Optional |
| RFID(2 user cards) | Optional |
| RCD | Type A/ type A+6mA DC |
| 5 inch display | Yes |
| LED Indicator light | Yes |
| Home load balancing(DLB) | Optional |
| IP grade | ≥IP55 |
| Working temperature | -40~+65℃ |
| Working ltitude | ≤2000m |
| Working Humidity | 5%-95% no condensation |
| Cooling mode | Natural cooling |
| MTBF | ≥100000H |
| Standby power | 3W/5W(With LCD) |
| Special protection | UV resistance |
| Dimension | 544(H) x 409(W)x 145(D)mm |
| Cable length | 5M[16.4FT) standard,or other size customizable |
| Weight | 21.6kg (Including charging gun) |
| Certificate | CE,OZEV LIST,UKCA,SASO.TUV.CB |
1. Minimally designed screenless body, dust-proof and easy to maintain
Adopting a screen free integrated minimalist design, the body is flat without grooves or dust accumulation areas, making it less prone to dust and stains. It does not require complex cleaning and maintenance in daily life, and has a lower structural failure rate. It is clean and durable for long-term wall mounted use, suitable for various home decoration and commercial scenarios.
2. Breather light intelligent display, status visualization
Equipped with an exclusive blue breathing light, it can accurately distinguish between charging, ready, and standby modes through three lighting states: constant on, flashing, and off. The visual feedback is intuitive and clear, suitable for all ages, and can be easily used without learning.
3. Pure plug and play, zero threshold operation
Abandoning cumbersome activation methods, no need for APP, no need for card swiping, no need for debugging, automatic charging when inserting the gun, completely solving the pain points of complex operation of smart devices, suitable for users of all ages in the family, and maximizing the convenience of use.
4. Level 6 safety protection, zero hidden dangers during charging
Integrated A-type RCD+6mA DC leakage detection, 0.1 second fast power-off to prevent electric shock, combined with comprehensive protection against overvoltage, undervoltage, overcurrent, surge, lightning protection, and high temperature, multiple guarantees to prevent charging safety accidents and ensure more reliable use.
5. Compatible with all models and globally compatible
Standard Type2 European standard interface is standard, compatible with over 99% of domestic and foreign new energy vehicle models such as Tesla, BYD, NIO, Xiaopeng, etc. It is compatible with mainstream global vehicle models and has strong universality, making it worry free to adapt to both household and commercial scenarios.
1. European household users
“This CAMC Type2 charging station has a simple and high-end design, with no screen or dust accumulation on the body, making daily maintenance very convenient. The plug and play mode is particularly suitable for elderly people at home, without the need for complex operations. The breathing light status is clear, and multiple safety protections make home charging very reassuring. It is compatible with my new energy vehicle and has an excellent experience. ”
2. Southeast Asian community operation and maintenance providers
“The users of community public charging equipment are complex, and this charging station has zero threshold operation and is compatible with a wide range of vehicle models, almost suitable for all owners' vehicles. The body is sturdy, dust-proof, fully protected, and has an extremely low failure rate. It does not require frequent operation and maintenance, greatly reducing our operational and management costs, and the cost-effectiveness is extremely high. ”
Q1: What is the biggest feature of the CAMC Type2 charger?
A: It adopts a screen-free minimalist design with a blue breathing light for intuitive status display. It supports true plug-and-play without APP or card activation, realizing zero-threshold charging for all users.
Q2: How does the breathing light indicator work?
A: Steady blue light means charging normally; flashing light means ready for charging; light off means standby or power off. The working status is clearly visible in real time.
Q3: What safety protection functions does it equip?
A: It builds full-level safety protection, including Type A RCD + 6mA DC leakage detection with 0.1s fast power-off, over-voltage, under-voltage, over-current, surge, lightning and high-temperature protection.
Q4: What car models are compatible with this charger?
A: Equipped with a standard Type2 European charging gun, it is compatible with more than 99% of domestic and imported new energy vehicles such as Tesla, BYD, NIO and XPEV, with ultra-high universality.
Q5: What scenarios is it suitable for?
A: With dustproof, durable and easy-to-operate features, it is perfectly suitable for household wall-mounted installation, community public charging and commercial supporting charging scenarios.
