CAMC electric dock tractor is a zero emission transportation solution designed specifically for modern intelligent ports. It relies on CAMC's new energy core technology, integrates efficient power and flexible loading and unloading performance, and perfectly adapts to the heavy transportation needs of ports such as containers and bulk cargo. It has been widely used in major ports in China, redefining port transportation standards with its core characteristics of "zero emissions, strong power, and high flexibility". At the same time, it has passed international certification and is exported in bulk to overseas port markets such as Southeast Asia and the Middle East, becoming the preferred equipment for global intelligent port green transformation. The vehicle is equipped with a 220kW (peak 360kW) permanent magnet synchronous motor, paired with a 4-speed AMT gearbox, providing stable and strong power output with abundant torque, making it easy to cope with complex working conditions such as port heavy load traction and frequent start stop; Equipped with a 282kWh lithium iron phosphate battery, it supports two energy replenishment modes: 6-minute high-speed battery replacement and 1-hour dual gun fast charging, completely eliminating range anxiety and adapting to the high-frequency operation rhythm of ports. The upgraded version in 2026 integrates a 5G intelligent scheduling system, which can achieve remote monitoring and automated operation cooperation, further improving the efficiency and intelligence level of port transportation. The vehicle adopts a compact structure design, flexible steering, and adapts to the narrow working space of ports. At the same time, it has the advantages of low noise and low energy consumption, which is in line with the global trend of green environmental protection and intelligent upgrading of ports. Relying on CAMC's perfect overseas after-sales service system, it provides efficient, environmentally friendly, intelligent, and convenient transportation solutions for global port users, demonstrating CAMC's technical strength and global market competitiveness in the field of new energy port equipment.
| Type | Battery replacement type of dock tractor |
| Model | HN4180D20C8BEV |
| Driving model | 4×2 |
| Wheelbase (mm) | 3800 |
| Overall dimension (mm) | 6170×2550×3450 |
| Kerb weight (Kg) | 9500 |
| GVW (kg) | 42000 (Overload:75T) |
| Front/Rear radius of gyration (mm) | 1800/1600 |
| Ratio of driving axle | 16T（Optional:13T）/ Ratio:11.98 |
| Motor type | Permanent magnet synchronous moto |
| Motor rated/peak power (kW) | 220/360 |
| Motor rated/peak power (N.m) | 1500/2100 |
| Gearbox | 4shift, AMT |
| Power Battery | Lithium iron phosphate(CATL) |
| Power Battery specs | 618.24 V，281.92 kWh，141 kWh |
| 0~50km/h Acceleration time (s) | 20 |
| Maximum speed (km/h) | 40 |
| Maximum climbing grade (%) | 20 |
| Driving range under standard load combined condition (km) | 80~130 |
| Power on mode（charging/battery replacement | DC dual guns/battery replacement |
| Charging/battery replacement time | Charging 1h, Battery replacement＜6min |
1. Zero emission and efficient, powerful: Equipped with a 220kW (peak 360kW) permanent magnet synchronous motor and a 4-speed AMT gearbox, the power output is stable, the torque is abundant, zero emissions, low noise, suitable for port heavy-duty traction and frequent start stop conditions, and meets the needs of green port development.
2. Convenient energy replenishment without range anxiety: Equipped with a 282kWh lithium iron phosphate battery, it supports 6-minute high-speed battery swapping and 1-hour dual gun fast charging, making energy replenishment efficient and fast, completely solving the pain points of port operation range and ensuring operation continuity.
3. Intelligent upgrade, outstanding efficiency: The 2026 upgraded version integrates a 5G intelligent scheduling system, which can achieve remote monitoring and automated operation collaboration. Combined with a compact and flexible body design, it is suitable for small spaces in ports and greatly improves operation efficiency.
4. Global adaptation and outstanding reputation: widely used in major ports in China, certified internationally, and exported in bulk to ports in multiple overseas regions; Reliable quality, perfect after-sales service, suitable for the green transformation needs of global smart ports, and recognized by global users.
1. Director of Operations at an international port in Southeast Asia: “We are promoting the green and intelligent transformation of the port, and the performance of CAMC electric terminal tractors fully meets expectations. The 220kW permanent magnet synchronous motor has strong power, with a peak of 360kW, making it easy to handle container heavy load traction. The 4-speed AMT gearbox shifts smoothly and is suitable for frequent start stop operations in ports. The 282kWh battery paired with a 6-minute battery swapping mode completely solves the anxiety of battery life. The upgraded 5G intelligent dispatch system in 2026 enables remote monitoring and automated collaboration, greatly improving our operational efficiency. The zero emission characteristics also comply with local environmental policies and have been put into mass use. ”
2. Procurement Manager of a Port in the Middle East: “Our port mainly engages in container and bulk cargo transportation, and has strict requirements for the flexibility, power, and environmental friendliness of the tractor. This electric dock tractor perfectly meets the needs. The compact body has flexible steering, adapts to the narrow working space of the port, and the permanent magnet synchronous motor has stable power, zero emissions, and low noise to improve the port operating environment. The 1-hour dual gun fast charging can quickly replenish energy, ensuring uninterrupted operations. The 5G intelligent scheduling system facilitates our unified management, and coupled with comprehensive overseas after-sales support, it has become the core equipment for green transportation in our port. ”
CAMC International is a leading enterprise in China's heavy-duty vehicle industry. As a national key R&D and production base for heavy-duty vehicles, specialized vehicles, and core components, the company has maintained a leading position in the industry since its establishment in the 1970s. As the only truck manufacturer in China with the ability to independently produce the entire industry chain including engines, transmissions, axles, chassis, and cab, CAMC has achieved complete autonomy and controllability from key components to the entire vehicle.
Relying on the research and development capabilities of national level technology centers, the company's products cover a full range of commercial vehicles such as heavy-duty trucks, engineering dump trucks, and special transport vehicles, which are widely used in infrastructure, mining, logistics, and other fields. With the advantage of a complete industrial chain and continuous technological innovation, CAMC not only occupies an important position in the domestic market, but also exports its products to more than 80 countries and regions around the world. As a high-end equipment manufacturing enterprise supported by national policies, the company is continuously promoting the upgrading and development of China's commercial vehicle industry towards intelligence and green direction.
Q: How many engines can your factory produce annually?
A: Hello, we can produce nearly 100000 units annually. Nearly 8500 units per month.
Q: Do you accept custom order? What's is your MOQ order?
A:Yes, we do. Our MOQ is 1 unit.
Q: Do you have ISO certification?
A: Yes, we have ISO, CCC, BV certifications. Please contact us to obtain the certificate.
Q:How to choose the right model?
A:It depends on continuous output power, Voltage, Frequency and fuel type.
Q:How is the after sale service and maintenance ?
A : We offer installation, repair and maintain service abroad. And online quide service if needed anytime. Our before-sale, in-sale and after-sale service are all trustable, you can name it.
Q: How do you control the quality of the product?
A: Our factory has standard production workshops and our workers are well-trained. Every product undergoes a rigorous inspection process.
Q: How about your product after-sales service system?
A:Our main export countries have accepted after-sales service, some countries use the third party service.
Q: What's the payment terms?
A:By T/T or L/C at sight.
Q: How about shipment?
A:20FT container, 40FT container, 40FT high container, open-top container, flat bed container, Ro-Ro ship or bulk ship according to the size the products.
Q:Which country do you have exported to?
A:We have exported to More than 60 countries and regions in Eastern Europe, North Africa, Southeast As
