The CAMC 6 × 4 methanol mainline traction unit is a new energy equipment specially designed for long-distance logistics and intercity freight scenarios. It is powered by clean energy methanol and accurately balances the mileage requirements and low-carbon operation characteristics of long-distance transportation. It has become the preferred green transportation equipment in the field of mainline logistics and has passed international certifications such as the EU ECE. It has been exported in bulk to multiple countries and regions such as Indonesia, Saudi Arabia, and Latin America, demonstrating CAMC's technical strength and global market competitiveness in the field of methanol new energy commercial vehicles. The vehicle is equipped with the GS13M480H-60 methanol engine, with a rated power of 338 kW and a rated horsepower coverage of 270-550 hp. The power output is strong, abundant, clean, and low-carbon. It is equipped with a 510L+620L large capacity methanol tank, which, combined with the advantages of high energy density and convenient refueling of methanol fuel, can fully meet the endurance needs of long-distance mainline transportation and effectively solve the anxiety of long-distance transportation mileage; The driver's cabin is equipped with the classic flat roof of CAMC LHD, with a luxurious interior. It is also equipped with air conditioning, radio, mechanical shock absorbers, mechanical shock absorber seats, and supports Bluetooth and MP3 functions, which comprehensively improve the comfort of long-distance driving and relieve driver fatigue from long-term work. Relying on CAMC's perfect overseas after-sales service system, it provides multilingual technical support, 24-hour call response, and global spare parts supply, providing efficient, low-carbon, reliable, and comfortable long-distance transportation solutions for global trunk logistics users.
| Information about the truck | Model | JHC4250GM6N1 |
| Engine model | GS13M480H-60 | |
| Engine power | 338 | |
| Geerbox | 12JSDX220TA-B | |
| Type of fuel | Methanol | |
| Emission standards | GB14763-2005, GB17691-2018 | |
| Approach/departure angle | 16/30 | |
| Basic parameters | Overall dimension(mm) | 6950*2550*3970 |
| Number of axles | 3 | |
| Wheelbase(mm) | 3400+1350 | |
| Wheel track(mm) | Front:2070 Rear:1850/1850 | |
| Front overhang/Rear overhang(mm) | 1450/750 | |
| Drive form | 6*4 | |
| Kerb weight(Kg) | 8870 | |
| Maximum total mass(Kg) | 25000 | |
| Total mass of quasi-trailer(Kg) | 40000 | |
| Maximum speed(km/h) | 89Km/h | |
| Front Axle | 7T lightweight | |
| Middle rear Axle | HL439 | |
| Retarder | Hydraulic retarder | |
| Number of tires | 11(Spare tire included) | |
| Tire specifications | 12R22.5 18PR | |
| Methanol tank | 510L+620L | |
| Interior and exterior room arrangement | Skylight | Power |
| Window | Power | |
| Main driver's seat | Ventilated and heated airbag seats | |
| Rearview mirror | Electric heating | |
| Steering wheel | Multifunction steering wheel(Optional） |
1. Clean and efficient, powerful: Equipped with GS13M480H-60 methanol engine, powered by clean energy, low-carbon and environmentally friendly, with emissions standards. The rated power is 338kW and the rated horsepower is 270-550hp, covering a wide range of power and perfectly adapting to the heavy-duty traction needs of long-distance logistics and intercity freight transportation.
2. Adequate endurance, suitable for long-distance travel: Equipped with 510L+620L large capacity methanol tanks, combined with the characteristics of methanol fuel, the endurance is stable and abundant, which can fully meet the mileage requirements of long-distance trunk transportation without frequent energy replenishment, improving long-distance operation efficiency.
3. Comfortable and convenient, driving friendly: CAMC LHD classic flat roof cab, luxurious interior with air conditioning, radio, mechanical shock absorbers, shock-absorbing seats, supports Bluetooth MP3， Significantly improve long-distance driving comfort and operational convenience, alleviate long-distance driving fatigue.
4. Global adaptation and improved after-sales service: Through international certification, we export in bulk to multiple overseas regions, meeting the low-carbon transformation needs of global trunk logistics; Relying on the improvement of overseas service system, convenient operation and maintenance, and completely solving customers' worries about long-distance operations.
Start & Driving: After power-on, wait for the system self-check to complete, select the corresponding power mode to start; switch between eco/power modes according to road conditions during driving;
Energy Supplement Operation: After arriving at the energy supplement station, connect the energy supplement equipment as guided, and start the energy supplement process after confirming parameter matching;
Traction Operation: When hitching the trailer, confirm the connection is locked in place; observe the trailer status during driving, and reserve sufficient radius when turning;
Daily Maintenance: Regularly check the status of key components of the power system, and confirm the sealing of equipment interfaces after energy supplement.
1. Southeast Asia's long-distance logistics operations director: “Our main business is cross-border long-distance logistics and intercity freight, and the CAMC 6 × 4 methanol mainline traction unit fully meets our needs. The GS13M480H-60 methanol engine is clean and low-carbon, with a power of 338kW and 270-550hp horsepower that can easily handle heavy-duty traction. The 510L+620L methanol tank has sufficient range and does not require frequent refueling. The classic flat roof cab is comfortable, equipped with air conditioning, shock-absorbing seats, and other features that greatly alleviate driver fatigue during long-distance driving. Bluetooth and MP3 functions enhance the work experience, and have been widely used in long-distance logistics fleets. ”
2. Procurement Manager of a Middle Eastern intercity freight transportation company: “We focus on intercity heavy-duty freight transportation, emphasizing low-carbon compliance and operational efficiency. This methanol mainline traction unit performs outstandingly. Methanol clean energy meets local environmental requirements, with strong power and stable range. The large capacity methanol tank is suitable for long-distance transportation needs, and the luxurious interior and rich configuration make long-distance operations more comfortable for drivers. With comprehensive overseas after-sales support and worry free operation and maintenance, it has become our main model for intercity freight transportation. ”
CAMC International Trading Co., Ltd.is a branch company of CAMC, mainly in charge of overseas marketing. CAMC is the national priority production and research development base of heavy trucks, special purpose heavy vehicles and spare parts, which is also the state mainly supports enterprise.Located in Maanshan Economic and Technology Development Zone, Anhui, China, CAMC was found in 1970s and we are the only truck enterprise in China which is capable of producing everything on our own including engine, gearbox, axles, chassis, cabin and so on.Our company is specialized in different kinds of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with an irresistible force.
For years, CAMC has been doing good and professional work in commercial vehicles. Our product covers a huge scope in this field, like tractor truck, dump truck, concrete mixers, pump truck, cargo truck, garbage truck, crane truck, bulk cement truck, tank-carrying truck, semitrailers and other special vehicles along with different driving form such as 4X2, 6X2, 6X4, 8X4, 10X4. The emission standard covers a range from EURO 2 to EURO 6.Besides,we are convinced that high-quality, systematic, comprehensive and efficient service are the foundation of our career development. With the goal of creating a domestic first-class service enterprise with strict management and advanced technology, we have formulated a "standardized management system, strict process control, guaranteed product management, and quality policy of customer satisfaction, adhered to the far side of customer first, and built good sales and series system, providing customers with high-quality pre-sale, in-sale and after-sale services.
Q: How do you control the quality of product?
A:Our Factory has standard production workshop,gets ISO CCC BV certificates,our workers are well trained. Every unit of product undergoes a rigorous inspection process.
Q:What are the advantages of the new product？
A:A variety of system configuration: weight, cost, fuel saving rate to achieve optimal. To realize the engine directly mounted generator, high efficiency.
Q: What are the smart features of this new product？
A:Blind area monitoring, driving behavior detection, Internet of vehicles cloud services , one button to open the environmental protection dust suppression system, material real-time monitoring, remote intelligent addition, positive and negative cylinder detection, mileage, fuel consumption, positioning monitoring.
Q:What's new about the new product?
A:Quality compliance, to solve the problem of licensing. Dimensions compliance, announcement photo compliance.
Q: How about your product after-sales service system?
A:Our main export countries have accepted after-sales service,some countries use the third party service.
Q:Why choose you?
A:Our brand has decades of reputation, our factory has the country's top technology, our workers are serious and responsible, to ensure the high quality of every product and we provide you with quality after-sales service.
Q: Do you accept custom order? What's is your MOQ order?
A:Yes, we do, our MOQ is 1 unit.
Q: What's the payment terms?
A:By T/T or L/C at sight.
